The Atmel-ICE Basic kit includes the cable you need. You can be a little cheaper and just get the PCB (no case) for ~$35 but you also need the ribbon cable which costs ~$15 so you only save $5 and don't get a protective case.
If you already have an Atmel SAM-ICE or Segger J-Link those will work too. They're generally more expensive, so I wouldn't buy one now, but they're useful if you have one laying around...
I have been bugging the crap out of John trying to clarify the simplest of questions. You see I always look the info offered literally, and this often over complicates things for me.
Anyways here is a set of instructions given to flash the TG2/V9 via the Arduino Due IDE. (link there https://github.com/synthetos/g2/wiki/Flashing-G2-with-Windows)
Step 3a - Program TinyG2 onto the Due Using Arduino Tools
From Cmd line they say to Change Directory to
After that go ahead and run these commands.
--> mode COM6 BAUD=2400
OK, I get what is happening. I am supposed to sub the COM6 for my COM. Easier said then done. First off it was not clear how to get the TinyG2/v9 board to even be recognized by window as a com.
The only way I could do it was to copy the TinyGv2.inf from git hub to my pc, then update the driver for the TinyGv2 that was populated two times in the "Other Devices" of the Windows device manger (Yellow triangle with Exclamation). I hat to Right Click and manually update driver. I had to browse to the TinyGv2.inf and load it as a driver. It was then that one of the two TinyGv2 "Other Devices" icons become a port 10 device called TinyG v2 (Control Channel) (COM10) you can see it here http://gyazo.com/77fd4d29264fb931550defaef1397c52 . That only took and hour or so to figure out, lol
So now I am supposed to run " mode COM6 BAUD=2400 " but sub my com. "mode COM10 BAUD=2400 " This defines COM10's baud rate to 2400 correct?
Next I am supposed to run " bossac.exe --port=COM6 -e -w -v -b %HOMEPATH%\Downloads\TinyG2_Due_rob_usbtest.bin -R"
Well I have no bossac.exe in the ProgramFiles\(x86)\Arduino\hardware\tools folder. I am running the latest Arduino IDE 1.6.5 r2. and the only place I can find anything that says bossac is bossac.inf and its C:\Program Files (x86)\Arduino\drivers in a zip folder called Old_Arduino_Drivers.zip
Can you please break down this string for me.
bossac.exe --port=COM6 -e -w -v -b %HOMEPATH%\Downloads\TinyG2_Due_rob_usbtest.bin -R"
Correct me if I am wrong, since we are in the C:\Program Files (x86)\Arduino\hardware\tools directory, that command is trying to run the bossac.exe (but I don't have this .exe) next it defines the port for the TinyGv2 (again mine is COM10), then I have no clue what -e -w -v -b is, (can someone explain please), next it defines the HOMEPATH to the compiled G2 code base, which from that string says look in the downloads folder for a file called TinyG2_Due_rob_usbtest.bin, and and load it to the TGv2 board.
Again, please can someone tell me what the -e -w -v -b are called, and what they do. Lastly at the end of the string I see a -R, that must be reset right?
Guys, I am not a real coder and I do not have a lot of experience working in cmd line. I want to learn so I can at least explain it well enough in a video so others that know even less than I (if that's possible, lol) can get an easier start using these boards.
In summary, I don't have a bossac.exe, and if I do, its for sure isn't located in the ProgramFiles\(x86)\Arduino\hardware\tools folder. I am happy I have TinyGv2 on Com10. I am going to see if I can putty in, or coolTerm in.. Just as I started to get a handle on V8, now I am on V9... This is a good thing, and I cant wait to share my journey.
I don't think that the avrdude utility is properly installed on your Windows machine, since it can't find it's configuration directory. You could work on that while waiting for TinyG to return. Could be an environment variable, or perhaps you need to explicitly include the config directory in the command line call. Unfortunately, I am not familiar with the Windows version of avrdude.
Is there a list in order of the builds? Is 384.04 a custom build that was installed on the board before shipment? Is it possible to use the App to flash to an earlier version?
Sorry for the random questions here. Thanks, T
The link below shows the circle warning in JScut
This link below shows the holes selected as a group of paths in illustrator.
I am trying to do what you told me before which was to separate the outside from the inside operations so I can control when the outside of the part gets cut out.
Sorry, o bother you again about this, still trying to get a workflow setup for my buddy. He is a real mess. He uses Flexisign to create stuff. then had to send it to AI just to convert to SVG (what a mess).. He is too stubborn to learn a new package, I say whatever.
If I can get this grouping of paths working for JScut, I can be done with him.. (for now at least)
Just sent 21921 lines of Gcode to it via . Its working like a champ. Thanks , now to get the move behind me and do some builds, and cut some parts!
I just want to know how to contact the Dev Team, and or how to join this team to test some of my ideas. I really have some good stuff to offer.
G+ is a cool place, however the formatting is extremely limiting. At minimum, there should be a button to open a thread as a full page. Also there should be a image upload button (instead of having upload a photo then paste a link).
It seems that would be a simple task.Click a button, and it opens a G+ image folder (in your G+ photos), and then pastes the link in a post automatically. Even I could do that.
Also it would be nice to have a My posts tab (like the mentions), so I can look at all of the response activity quickly, and in one place.
Personally I like G+, but many folks I have invited to my community's rather use a forum or Google Groups than G+. I think G+ needs to keep tweaking to make it better and better every day. Most of all, they need to remain Ad free :).
Well the search continues. Thanks for your time in response.
Welcome to the community. T
FWIW, I prefer the Google Groups interface over communities for detailed discussions - the Community UI wastes too much screen space (my opinion).
But everyone has a personal preference and mine is no better than yours.
The JSCut generated Gcode (see link below) that stops the tool a few mm of movement into the routine.
Delay Per Gcode Upload Event (i.e. per line) set to 2ms, and it needs to be 1000ms
The Json Server/TinyG buffer (in the port list) was at 4000, and the TinyG buffer (just below Freehold) was as 34/34.
So if you read back to where I wrote it seems like the TinyG is getting slammed with too much Gcode, I was kind of right.
So I set him up, and the machine ran first time no problems. On the last path, his spoiler board shifted and (the g10 being cut too) and broke the bit. I guess my Torque settings are good, :)
I hope he is good to go, he need to get his clamping system, as well as dust collection up and going. I think I am done with him..... wait, I still have to help him with his RB Pi2 Grrrr.
