SEM Lab, Inc.

Shared publicly  -

Solder mask misalignment can cause BGA solder joint distortions that weaken individual ball attachments.
1
Add a comment...

SEM Lab, Inc.

Shared publicly  -

This is an LED microsection where the open circuit failure was caused by the die and lens material separating from the bottom of the cup and rupturing the die attachment.
1
Add a comment...

SEM Lab, Inc.

Shared publicly  -

This is an example of "black pad syndrome" (BPS) combined with ball grid array (BGA) warpage causing brittle interfacial fracture between the Ni3Sn4 intermetallic compound (IMC) and the electroless nickel (EN) pad surface on an electroless-nickel immersion-gold (ENIG) finished printed wiring board.
1
Add a comment...

SEM Lab, Inc.

Shared publicly  -

One way to identify counterfeit tantalum capacitors is to microsection them and measure the dielectric thickness.   Counterfeits can be relabeled with the wrong voltage rating.

see also http://www.semlab.com/IDCounterfeitParts.html
1
Add a comment...

SEM Lab, Inc.

Shared publicly  -

Types of analysis done in 2012 by SEM Lab.
1
Sofia Andrews's profile photo

You can score free professional help from RDM,they do free PPC campaign audits, just call them at 256-398-3835
Add a comment...
In their circles
5 people
Have them in circles
8 people
Inspyder Software Inc.'s profile photo
Ed Hare's profile photo
BBB serving Alaska, Oregon & Western Washington's profile photo
Stephanie Hare's profile photo
Eric Hare's profile photo
Tan Lisa's profile photo

SEM Lab, Inc.

Shared publicly  -

SEM Lab, Inc. has seen the same type of resistor failures repeatedly since ~ 1997 when we were founded. The trigger appears to be the local environment where the resistors are deployed, for example ...

A computer module in a tractor.
Fireworks display controller. Boards coated with ~ 0.300 inches of Dow Corning "tough gel".
A display at an outdoor drive-up kiosk.
Many other previous analysis efforts where the source of sulfur is unexplained.
The problem, sulfur pollution and corrosion of silver, is illustrated in Fig. A and explained thoroughly in references [1] & [2]. The resistors increase in value and eventually fail open.

http://www.semlab.com/resistorcorrosion.html
1
Add a comment...

SEM Lab, Inc.

Shared publicly  -

This is a PTH solder joint where the land on the solder side of the board has lifted due to a combination of excessive z-axis expansion of the laminate during wave solder and shrinkage stress in the solder fillet on cool down.
1
Add a comment...

SEM Lab, Inc.

Shared publicly  -

This is a chemically decapsulated SMD diode that failed due to excessive current electrical overstress (EOS).  The bond wire fuses open near the center of the span because it is heat-sunk at both ends.
1
Add a comment...

SEM Lab, Inc.

Shared publicly  -

This is a flex crack in MLCC caused by breakout of PCBA from panel.  The PCBA layout during the design phase is critical in preventing this type of failure.
1
Add a comment...

SEM Lab, Inc.

Shared publicly  -

This is residual activated solder flux on a PCBA.  This causes corrosion of the tin-based solder alloy and copper circuit traces.  It can result in electromigration shorts on the surface of the PCBA.
1
Add a comment...

SEM Lab, Inc.

Shared publicly  -

Intermetallic compounds (IMCs) are generally considered a bad thing in solder joints, though this is not always the case. Excessive IMCs in solder joints are a bad thing since they significantly alter both the composition and the mechanical performance of the solder joint. Interfacial IMC layers can be an indication of the quality of the solder joint and the lack of them would indicate a solder process or possibly a material problem.

The intermetallic compounds that have been most important in our work performing microstructural evaluations on solder joints are described in this paper.

http://www.semlab.com/IntermetallicsinSolderJoints.html
1
Add a comment...
People
In their circles
5 people
Have them in circles
8 people
Inspyder Software Inc.'s profile photo
Ed Hare's profile photo
BBB serving Alaska, Oregon & Western Washington's profile photo
Stephanie Hare's profile photo
Eric Hare's profile photo
Tan Lisa's profile photo
Contact Information
Contact info
Email
Story
Tagline
Failure Analysis and Scanning Electron Microscopy
Introduction
SEM Lab, Inc. provides failure analysis, materials characterization, scanning electron microscopy (SEM) and FTIR services. We specialize in failure analysis of electronic assemblies, printed-circuit-boards (PCBs) or printed-wiring-boards (PWBs), and electronic components such as integrated circuits (ICs), memory chips, transistors, diodes, capacitors, resistors, light emitting diodes (LEDs), power modules, and many others.
